Sleeve Anchor Sizes: A Selection Guide for 8x75, 8x100, 10x85, and 10x110

When selecting a steel sleeve anchor, simply saying “sleeve anchor” is often not enough. The diameter and length of the anchor play a crucial role in determining the right product for the intended connection.

While there are sleeve anchors of different diameters and lengths on the market, the Dubell Pro product line includes 8x75, 8x100, 10x85, and 10x110 steel sleeve anchor options.

So, what do these measurements mean? What is the difference between 8x75 and 8x100? What should be considered when choosing between 10x85 and 10x110 sleeve anchors?

In this guide, we cover sleeve anchor sizes and the key points that should be evaluated when choosing the right size.

What is a Steel Sleeve Anchor?

A steel sleeve anchor is one of the steel fasteners used in mechanical fastening applications made into suitable solid base materials such as concrete.

The metal sleeve structure of the anchor expands during installation, helping to create mechanical adhesion within the base material.

Because of this structure, steel sleeve anchors can be used in different applications such as metal profiles, steel constructions, shelving systems, consoles, machinery, and equipment.

However, it is just as important to determine the right size as it is the type of anchor to be used.

What Do Sleeve Anchor Sizes Mean?

Sleeve anchors are generally defined by expressions such as 8x75, 8x100, or 10x110.

For example:

10x85 sleeve anchor

In this expression, the first value represents the nominal diameter of the product, and the second value represents the length measurement.

Therefore, two sleeve anchors with the same diameter can have different lengths.

For example:

8x75 → 8 mm diameter class / 75 mm length
8x100 → 8 mm diameter class / 100 mm length

Although both are in the same diameter group, their lengths are different.

This difference can gain importance due to factors such as the thickness of the part to be fixed and the necessary anchorage/installation conditions.

What Are the Sleeve Anchor Sizes?

The steel sleeve anchor sizes available at Dubell Pro are:

Now let's look closer at the differences between these four sizes.

8x75 Steel Sleeve Anchor

The 8x75 steel sleeve anchor is a sleeve anchor option in the 8 mm diameter class with a length of 75 mm.

It can be considered for applications where metal parts need to be mechanically fixed to suitable concrete surfaces, provided the project and installation requirements are met.

When choosing an 8x75, the thickness of the part to be fixed, concrete properties, required installation depth, and the expected performance from the connection should be taken into account.

You can examine the 8x75 steel sleeve anchor product at Dubell Pro and get a quote for your high-volume needs.

→ Examine the 8x75 Steel Sleeve Anchor product

8x100 Steel Sleeve Anchor

The 8x100 sleeve anchor is in the same 8 mm diameter class as the 8x75 but has a length of 100 mm.

Therefore, one of the main differences between the 8x75 and 8x100 is the anchor length.

The 8x100 option can be considered in applications where a longer anchor might be needed. However, a selection should not be made solely on the basis that “it is stronger because it is longer.”

The correct product should be determined based on the thickness of the material to be fixed, the base material, the required anchorage depth, and the technical requirements of the project.

→ Examine the 8x100 Steel Sleeve Anchor product

10x85 Steel Sleeve Anchor

The 10x85 steel sleeve anchor is an option in the 10 mm diameter class with a length of 85 mm.

Sleeve anchors in the 10 mm group can be considered, especially in applications that require mechanical fasteners with larger diameters.

When determining the product to be used in applications such as fixing metal profiles, steel parts, consoles, or similar elements to concrete surfaces, the structure of the part to be fixed and project requirements should be considered alongside the anchor diameter.

→ Examine the 10x85 Steel Sleeve Anchor product

10x110 Steel Sleeve Anchor

The 10x110 sleeve anchor is a steel sleeve anchor option in the 10 mm diameter class with a length of 110 mm.

Although it is in the same diameter group as the 10x85, it has a longer structure.

For this reason, it can be considered for suitable applications that require a longer anchor. However, a selection between 10x85 and 10x110 should not be made solely by looking at the length.

The base material where the connection will be made, the thickness of the part to be fixed, the required installation depth, and the technical requirements of the project should be evaluated together.

→ Examine the 10x110 Steel Sleeve Anchor product

What Is the Difference Between 8x75 and 8x100 Sleeve Anchors?

Both products are in the 8 mm diameter group.

The main difference is the length:

8x75: 75 mm
8x100: 100 mm

Therefore, there is a 25 mm length difference between them.

The required anchor length may change as the thickness of the part to be fixed and installation conditions change.

The important point here is to avoid the assumption that a longer anchor is automatically more correct for every application.

What Is the Difference Between 10x85 and 10x110?

A similar situation applies to the 10 mm diameter group.

10x85: 85 mm
10x110: 110 mm

There is again a 25 mm length difference between the two products.

Although both are in the 10 mm diameter group, they offer different length options.

Which size to use should be determined based on the characteristics of the connection to be made.

8 mm or 10 mm Sleeve Anchor?

It is not correct to generalize here that “10 mm is always better than 8 mm.”

The correct anchor diameter should be determined based on the part to be fixed, the base material, the type of installation, the characteristics of the connection point, and the performance required by the project.

Especially in load-bearing or safety-critical connections, the technical values provided by the manufacturer and the project requirements for the product must be taken as a basis.

Where Are Sleeve Anchors Used?

Steel sleeve anchors can be used in different professional and industrial applications.

Examples include:

• Metal profile fastening
• Steel construction applications
• Shelving systems
• Console and bracket connections
• Machinery and equipment installations
• Steel plate fastening
• Industrial assembly applications

However, the type and size of the anchor to be used should be evaluated separately for each application.

How to Choose a Sleeve Anchor Size?

Several factors should be evaluated together when determining the correct sleeve anchor size:

Thickness of the part to be fixed: The thickness of the metal profile or plate can affect the required length.

Base material: The properties of the concrete or other suitable base material to which the anchor will be applied are important.

Anchor diameter: A diameter suitable for the connection and project requirements should be determined.

Installation depth: The necessary installation conditions must be met for the anchor to work correctly.

Application requirements: The expected performance from the connection and any engineering/project requirements should be taken into account.

Especially in critical connections, one should not decide based solely on the product size; the relevant technical documentation should be taken as a basis.

Sleeve Anchor or Wedge Anchor?

Another product encountered in metal and industrial fastening applications is the wedge anchor.

One of the main differences between a wedge anchor and a sleeve anchor is their mechanical working structures.

While the metal sleeve system plays an important role in a sleeve anchor, mechanical adhesion is created via the clip/expansion mechanism in a wedge anchor.

Therefore, which product to use should be determined according to the application.

→ Check out our guide on the Differences Between Wedge Anchors and Sleeve Anchors.

Steel Sleeve Anchor at Dubell Pro

Dubell Pro offers steel sleeve anchor options in different sizes for professional and industrial use.

Our available sizes:

8x75 Steel Sleeve Anchor
8x100 Steel Sleeve Anchor
10x85 Steel Sleeve Anchor
10x110 Steel Sleeve Anchor

In addition to standard orders, you can contact Dubell Pro for your high-volume and recurring product needs to request B2B and bulk pricing.

Frequently Asked Questions

What are the sleeve anchor sizes?

Steel sleeve anchors can be produced in different diameter and length options. Dubell Pro offers 8x75, 8x100, 10x85, and 10x110 steel sleeve anchor options.

What does an 8x75 sleeve anchor mean?

The expression 8x75 specifies the size of the anchor. The first value indicates the nominal diameter group, and the second value indicates the length of the product.

What is the difference between 8x75 and 8x100?

Both products are in the 8 mm diameter group. The length of the 8x75 is 75 mm, and the length of the 8x100 is 100 mm. There is a 25 mm length difference between them.

What is the difference between 10x85 and 10x110?

Both products are in the 10 mm diameter group. 10x85 is 85 mm, and 10x110 is 110 mm in length.

Can a sleeve anchor be used on a metal profile?

Steel sleeve anchors can be used in applications where metal profiles and similar parts need to be fixed to a suitable base material. The correct product and size should be determined according to the technical requirements of the application.

Should a sleeve anchor or a wedge anchor be used?

Both products can be used in different mechanical fastening applications. The selection should be made according to the base material, the part to be fixed, installation conditions, and the technical requirements of the project.
